Introduction to the size and specifications of automated intelligent breeding chicken cages
Chicken cages are chicken pens for raising fattened chickens
The material of chicken cage:
Plastic and metal materials, and metal materials are generally galvanized mild steel cold-drawn wire. The most common in the market is the metal frame type chicken coop, here is also the introduction of the most common this kind of chicken coop.
Specification of rack type chicken coop:
According to the most common types of chicken cages, do a simple specification introduction:
1, brooder cage: the total height of the cage body is about 1.7 meters, the cage frame foot height of 10 to 15 cm, the cage length of each single cage is 70 to 100 cm, the height of the cage is 30 to 40 cm, the depth of the cage is 40 to 50 cm, and generally 3 to 4 layers of overlapping cages are used. The mesh is generally rectangular or square, the aperture of the bottom mesh is 1.25 cm 1.25 cm, and the aperture of the side mesh and top mesh is 2.5X2.5 cm. The cage door is located in the front, the cage door gap adjustable range of 2 ~ 3 cm, each cage can accommodate about 30 chicks.
2、Breeding chicken cage: the overall width of 1.6 ~ 1.7 meters, the height of 1.7 ~ 1.8 meters. Single cage length 80 cm, height 40 cm, depth 42 cm. Mesh holes in the bottom of the cage are 4 cm 2 cm and the rest of the mesh holes are 2.5 cm 2.5 cm. Cage door size of 14 cm 15 cm, each single cage can accommodate 7 to 15 breeding chickens, the combination of the form of more than three overlapping.
3, egg cage: each single cage length 40 cm, depth 45 cm, front height 45 cm, back height 38 cm, the bottom of the cage slope of 6 ° ~ 8 °. The egg collection groove that extends out of the cage is 12 to 16 centimeters. The cage door is open at the front, 21 to 24 cm wide; 40 cm high, with the lower edge of the cage leaving a gap of about 4.5 cm from the bottom net for egg rolling. The aperture spacing of the cage bottom mesh is 2.2 cm, and the weft spacing is 6 cm. The aperture range of the top, side and rear mesh is more variable, generally the mesh warp spacing is 10-20 cm, and the weft spacing is 2.5-3 cm. Each single cage can hold 3-4 chickens, and the common combination forms are ladder, semi-ladder and overlapping [2] .
Advantages
Advantages of rack type chicken cage:
1. The mesh is smooth, preventing the chickens’ feet from being injured and infected. Encrypted mesh and bottom mesh can effectively prevent fatigue syndrome of laying hens. The mesh is galvanized, which improves the service life by 6-7 times.
2、High-density feeding saves land, saving about 50% of land compared with free-range type farming.
3、Centralized management saves energy and resources, reduces the incidence of poultry diseases, and the unique cage door design effectively prevents chickens from wasting feed by bobbing their heads up and down when feeding.
4、It can be adjusted according to the size of the site, and it can be equipped with automatic drinking water system.
Other detailed questions, welcome to call us for free access to equipment information.
Introduction to the characteristics of automated breeding equipment broiler cage
Broiler cage, specifically for broiler chicken farming production of chicken cages, in order to overcome the hard bottom of the cage caused by broiler chest inflammation, more than the use of high-quality plastic made of broiler cage set, chicks from the cage until sent to the abattoir, do not need to turn the cage, save the trouble of catching chickens, but also to avoid the chicken may happen to reflect the bad.
Common broiler cages are cave body cages, 3 or 4 layers overlap, its design and construction and egg cage is basically the same. High-density feeding saves land, about 50% more than free-range farming. Centralized management saves energy and resources and reduces the incidence of poultry diseases. The unique cage door design effectively prevents chickens from wasting feed by shaking their heads up and down when feeding. Field adjustment can be made according to the size of the site, and automatic drinking water system can be added.
The main advantages of broiler cage farming are:
1, high degree of automation: automatic feeding, drinking water, manure cleaning, wet curtain cooling, centralized management, automatic control, energy saving, improve labor productivity, reduce the cost of artificial feeding, and greatly improve the breeding efficiency of farmers.
2、Good epidemic prevention for chickens, effective prevention of infectious diseases: chickens do not contact with feces, which can make chickens grow healthier, provide a clean and comfortable growing environment for chickens, and greatly advance the meat time.
3、Save space, improve the rearing density: the density of cage rearing is more than 3 times higher than the density of flat rearing.
4, save breeding feed: cage chicken can save a lot of breeding feed, chickens are kept in the cage, the amount of movement is reduced, less energy consumption, less waste of material. Data show that cage farming can effectively save farming costs of more than 25%!
5、Sturdy and durable: Cage broiler complete sets of equipment using hot-dip zinc technology, corrosion-resistant, aging-resistant, the service life can be as long as 15 to 20 years.
Automated breeding equipment booking consultation
The importance of automated intelligent chicken rearing equipment in the livestock farming industry
The importance of chicken equipment in livestock farming is self-evident, they not only improve the breeding efficiency, but also to protect the welfare of animals, and promote the modernization of livestock farming. The following are several aspects of the importance of chicken equipment in detail:
1. Improve breeding efficiency
Automated Feeding and Drinking: Through automatic feeders and drinkers, automated chicken rearing equipment can precisely control the feeding amount and time of feed, as well as the supply of water, to ensure that chickens receive balanced nutrition and adequate water. This not only reduces the tediousness of manual operation, but also avoids the problem of uneven feeding or insufficient drinking water caused by human negligence, thus improving the breeding efficiency.
Automatic environmental control: Modern chicken equipment integrates an environmental control system that monitors the temperature, humidity, light and other environmental parameters in the chicken house in real time and automatically adjusts them as needed. This precise environmental control creates the most suitable growing conditions for chickens, promotes healthy growth and rapid development of chickens, and thus improves the breeding efficiency.
2. Reduce labor costs
Reduce manual operation: automated chicken equipment can automatically complete the tasks of feeding, drinking, egg collection, manure cleaning, etc., which greatly reduces manual labor intensity. This advantage is especially obvious for large-scale farms, which can significantly reduce labor costs and improve economic efficiency.
Intelligent management: through the Internet of Things technology and big data analysis, chicken equipment can realize intelligent management. Farmers can remotely monitor the breeding situation and adjust the breeding strategy in time only through computer or cell phone, reducing the dependence on labor.
3. Enhance animal welfare
Comfortable growing environment: Chicken equipment creates a more comfortable and healthy growing environment for chickens by precisely controlling environmental parameters. This helps reduce stress and disease incidence in chickens and improves their welfare.
Reduced human injury: Automated operation reduces direct contact between humans and chickens, reducing the risk of injury to chickens due to improper human handling. At the same time, the equipment can also personalize the management of chickens according to their growth needs and physiological characteristics, further enhancing animal welfare.
4. Promote industrial transformation and upgrading
Promote technological progress: the development of chicken equipment cannot be separated from the support of technology. With the progress of science and technology and the continuous upgrading of equipment, the technical level of the livestock breeding industry is also improving. This helps to promote the transformation and upgrading of the livestock breeding industry and sustainable development.
Enhance market competitiveness: farms that adopt advanced chicken raising equipment can improve production efficiency, reduce farming costs, and improve product quality and safety. These advantages make farms more competitive in the market competition, which is conducive to expanding their market share and improving economic benefits.
5. Meet the requirements of environmental protection
Reduce pollution: Automated chicken equipment reduces environmental pollution during the breeding process by automatically cleaning up manure and waste and other functions. At the same time, the precise control of the equipment also reduces the waste of feed and the production of waste, reducing the pressure on the environment.
Promote sustainable development: As people’s awareness of environmental protection increases and the government’s strict requirements for environmental protection policies, chicken equipment that meets environmental requirements will be more popular. This will promote the green development and sustainable development of the livestock breeding industry.
In summary, the importance of chicken rearing equipment in the livestock breeding industry is reflected in many aspects, such as improving breeding efficiency, reducing labor costs, enhancing animal welfare, promoting industrial transformation and upgrading, and meeting environmental requirements. With the progress of science and technology and the continuous development of livestock farming, chicken rearing equipment will play an increasingly important role in livestock farming.
